Trotec BB20 Coating Thickness Gauge

Product Description:
Trotec BB20 Coating Thickness Gauge dual sensor for measuring the thickness of non-magnetic coatings on all magnetic and non-magnetic metals.

Overview
Trotec BB20 Coating Thickness Gauge features an innovative dual sensor enabling measurement of non-magnetic coatings such as paint, varnish, synthetic coatings, zinc coatings, enamel and chrome on steel, iron and non-ferrous metals including aluminum, magnesium and titanium.

The spring-mounted measuring head with practical V-groove allows measurements on rounded objects like axles or hinges while minimizing vibration influence. The compact device can be operated with one hand and offers a measuring range from 0 to 1250 µm with precise results, statistical functions and an alarm function when predefined thickness thresholds are exceeded.

It is ideal for automotive inspection to detect repainting or accident repairs and can also be used on railings, boats, ships and other protective coatings.

Benefits in Practice

• Dual sensor for magnetic and non-magnetic metal surfaces
• Measuring range: 0 to 1,250 µm
• Alarm when thickness threshold exceeded
• Minimum, maximum and average statistical values
• Two-point calibration for high accuracy
• Memory for up to 400 measurements
• USB interface for PC data transfer
• One-hand operation
• Backlit display
• Auto power off

Measurement Specifications

• Measuring principle: Magnetic induction and eddy current
• Base material: Ferromagnetic and non-ferrous metals
• Measuring range: 0 – 1,250 µm
• Accuracy: ±0.1 µm
• Tolerance (0–850 µm ferromagnetic): (±3% + 1) µm
• Tolerance (850–1,250 µm ferromagnetic): ±5%
• Tolerance (0–850 µm non-ferrous): (±3% + 1.5) µm
• Tolerance (850–1,250 µm non-ferrous): ±5%
• Minimum measuring surface: Ø5 mm (non-ferrous), Ø7 mm (ferromagnetic)
• Minimum bending radius: 3 mm (non-ferrous), 1.5 mm (ferromagnetic)

Device Features

• Internal flash memory: up to 400 measured values
• LCD monochrome display
• Push button control
• Backlit display
• Automatic switch-off
• Acoustic alarm
• Standard deviation calculation
• Battery status indication

Operating Conditions

• Operating temperature: 0°C to 40°C
• Relative humidity: 20% to 90%

Dimensions and Weight

• Length: 110 mm
• Width: 24 mm
• Height: 54 mm
• Weight (device): 0.114 kg

Standard Scope of Delivery

• Measuring device
• Transport case
• USB cable
• Software
• Calibration accessories
• Operating manual
