ALLScanner VCX NANO PU100 for Land Rover / Jaguar USB JLR SDD Diagnostic Tool

ALLScanner VCX NANO PU100 for Land Rover / Jaguar USB JLR SDD Diagnostic Tool

Product Description: New ALLScanner VCX NANO PU100 for Land Rover / Jaguar USB JLR SDD Diagnostic Tool Software V164 Vcx-nano is a standardized VCI vehicle diagnostic interface, based on sae-j2534 and iso-22900 PDU international standard design, compatible with most of the vehicle communication protocols, compact design, is an ultra-high cost...

Categories : Diagnostic Accessories, Diagnostics

Description
Review

Product Description:

New ALLScanner VCX NANO PU100 for Land Rover / Jaguar USB JLR SDD Diagnostic Tool Software V164

Vcx-nano is a standardized VCI vehicle diagnostic interface, based on sae-j2534 and iso-22900 PDU international standard design, compatible with most of the vehicle communication protocols, compact design, is an ultra-high cost performance of the original diagnostic interface. VCX nano is widely used in ECU online diagnosis and programming by vehicle manufacturers. It also supports third-party and original diagnostic software.

Original diagnostic functions

The original factory level diagnostic function for various brand models supported, can replace expensive OEM equipment.
All kinds of advanced diagnostic functions are completely consistent with the original factory, and the performance even exceeds the original factory.
One click installation, original support driver and online upgrade, easy to use.

Meet the automotive industry standard design

SAE-J2534-1/2 Pass-Thru with EURO 5
ISO-22900 MVCI & D-PDU
J2534 original factory level ECU programming functions

PC communication interface

Support USB2.0 high speed connection
The PC configuration management tool provided automatically detects connections and updates firmware

High performance vehicle diagnostic interface

Vcx-nano with high speed processor is a high performance vehicle network interface
It can support most standardized and original private vehicle bus protocols
It can support up to 4-way can: 3-way high-speed can and single line can
Support multi-channel work at the same time, for example: support 2-wire can or K-wire work at the same time
Support programming voltage output: 5V ~ 20V FEPS output (Ford)
Compact design of integrated OBD-II interface can be connected directly with vehicle

Hardware specifications

Protocol processor	32bit 180MHz ARM
Memory	1MB FLASH
Diagnostic interface	SAE-J1962 standard, OBD-II diagnostic interface
Wired interface (PC)	USB Micro-B interface
Indicator lights	2 LEDs, Red: device status, Blue: communication status
Power supply	Vehicle power supply: DC 9v-36v (compatible with 12V and 24V)
Power	1W
Size	L x W x H = 140 x 50 x 25 (mm)
Weight	Equipment weight: 0.3KG, Product + package weight: 0.8kg
Shell	Reinforced plastic shell
Working temperature	-20～+70 °C
Storage temperature	-40～+85 °C
Standard certification	Comply with EU CE and US FCC
