FEATURES
- Monitor and Detect .010' Standard
- Test Natural Vacuum EVAP Systems
- Easy to Read Flow Control Knob Position
- Vacuum and Pressure Decay Gauge
- Stores in Your Tool Box on its Back Like No Other
- Find Leaks Using Smoke and UV Dye
- Smoke Wizard is the simplest tool with wide range in finding the leakage in the vacuum system, exhaust system, cooling system and the sealing of the cabin ( windows & doors rubber )
Specifications:
- Height (less hanger): 13 in. (33 cm)
- Length: 5.5 in. (14 cm)
- Width: 9.5 in. (24 cm)
- Weight: 10 lb. (4.5 kg)
- Shipping weight: 14 lb. (6.3 kg)
- Power supply: 12 volts DC
- Power consumption: 15 amps.
- Solution Max. Volume: 12 oz. (355 ml)
- Supply pressure: 13.0 in. H2O (0.032 bar)
- Supply volume: 10 liters per minute
- Smoke supply line: 10 feet (3m)
- Power supply line: 10 feet (3m)
- Operating temp range: 45°F to 140°F (7.2°C to 60°C)
- Altitude: Up to 6,561 Ft (2,000 M)
- Max Relative Humidity: 8600%° C for Temperatures up to 140°F
- Conditions of Use: Indoor / Outdoor (if not wet)
- Pollution Degree: 2
VIEW SPECIFICATION SHEET
