The LT240 is a floor plate two post lift equipped with an electric hydraulic power system.
Features
- Lifting capacity of up to 4.0T, catering to common passenger car maintenance scenarios;
- Adjustable tray with a minimum height of 95mm, suitable for sports car lifting;
- 120% dynamic and 150% static load testing compliant with CE standards;
- Pre-set rated hydraulic pressure with overload protection when lifting vehicles;
- Column width of 2850mm, suitable for wide vehicles like SUVs and commercial vans;
- Full-travel mechanical safety locks for easy and secure operation;
- Professional clod protective design, rubber door guard pads, foot protection bars, explosion-proof flow control valves;
- All movable points use automatic lubrication oil-free bearings to ensure long-lasting durability;
- Different release methods (two sides manual, one side manual, electric-magnetic).
Parameters
| Power Supply | 220V/380V | Lifting Time | ≤ 50S |
| Max Lifting Weight | 4.0T | Drive Mode | hydraulic drive |
| Max Lifting Height | 1920mm | Machine Power | 2.2kw |
| Min Lifting Height | 95mm | Hydraulic Oil | 10L wear-resistant hydraulic oil, provided by users |
| Total Height | 2824mm | Hydraulic Power Unit | 2.7ml/r |
| Distance between Columns | 2850mm | Work Environment | Temperature: 5~40°C Humidity: 30~95% |
