The TB293 intelligent type LCD wheel balancer revolutionizes workflow efficiency with its automated measuring scale, smart
calibration, and auto-positioning technologies, ensuring fast, simple, and precisely accurate balancing results
Features
- It employs a color high-definition LCD screen to monitor and display various operational statuses and parameters, featuring a flexible user interface;
- Multiple balancing operation modes enable functions such as unbalanced block clamping and pasting;
- The electronic measuring ruler automatically inputs the relevant parameters of the wheel rim;
- Intelligent automatic calibration function and automatic calibration function of electronic measuring ruler;
- Automatic fault diagnosis and protection function;
- Various wheel rims suitable for steel structures and aluminum structures;
- Standard protective cover, width ruler, electromagnetic brake;
- Add the automatic positioning function.
Parameters
| Rim Diameter Range | 10"-24" (256-610mm) | Ounce/Gram Conversion Option | Yes |
| Max Tire width | 1.5"-20" (40-510mm) | Balance mode | 9 |
| Max tire weight | 65KG | Noise | <70dB |
| Balance quality | ±1g | Net weight / Gross weight | 101KG / 121KG |
| Balance speed | 200r/min | Voltage | 220V 50HZ |
| Balance cycle | 8s | Power | 200W |
| Display the operation interface | LCD | Package size | 960 × 560 × 1250mm |
| Detection of location | 64 | Container loading quantity | 20GP-48pcs 40HQ-104pcs |
