The TC191 swing-arm type simple left-side assist tire changer is widely used in small and medium-sized auto repair shops, quick service and maintenance centers, and tire retail stores due to its simple structure, low cost, and easy maintenance.
Features:
- High-quality white steel tire removal tool, made of high-strength white steel, more durable;
- Thicker working plate, precision cast steel material claw, non-skid durable claw protection cover, high quality all-aluminum small cylinder;
- All the air nozzle connectors are made of copper;
- Metal hexagonal compression cover, with a beautiful design, sturdy and durable, without after-sales service;
- Tire removal structure, thickened shovel arm body, universal large shovel, high-quality large shovel protective cover, anti-slip rubber plate;
- Install the tire pressure regulator.
Parameters
| Rim Diameter Range | 10-20" (Outer clamping size) 12-22" (Inner clamping size) |
Voltage | 110V / 220V / 380V |
| Max Tire width | 13" (330mm) | Power | 0.75 / 1.1Kw |
| Max tire diameter | 39" (1000mm) | Net weight / Gross weight | 164 / 184kg |
| Working air pressure | 8-10bar | Package size | 985 × 770 × 885mm |
| Operating panel speed | 7rpm | Container loading quantity | 20GP - 36pcs / 40HQ - 108pcs |
| Bead Breaker Pressure | 2500kgf |
